with scene controller. Mannual Programming Enabled. (Overheat, Overload Protection) single phase both 110/220 VAC, 50-60Hz. (Green operated supplied by 24VAC/25mA). Cascadable, Upgradable Via USB Cable. Works as 10A dimmer x 1Channel, (Warning: never Load the Module in Total More than 10A MAX)

The Dimmer 6A is a powerful, single-channel AC dimmer module engineered to control high-current AC loads such as heavy-duty ceiling fans, incandescent bulbs, and dimmable LED lights in home automation and industrial control applications. Designed to handle up to 6 Amps, this robust dimmer is perfect for environments that demand stable, noise-free, and flicker-free performance.

Utilizing triac-based phase control, the Dimmer 6A offers precise dimming capabilities with electronic reliability, silent operation, and a longer lifespan compared to traditional mechanical dimmers. It’s compatible with Arduino, ESP32, Raspberry Pi, and other microcontroller platforms, making it ideal for DIY automation projects, smart switchboards, and custom control panels.

Whether you're automating a heavy-duty ceiling fan or integrating a lighting dimmer into a smart system, the Dimmer 6A offers dependable, smooth, and safe dimming functionality.

Key Features:

• Supports high-current loads up to 6 Amps @ 230V AC
• Single-channel phase-cut triac dimming
• Smooth, flicker-free dimming performance
• Compatible with Arduino, ESP32, Raspberry Pi, and PLCs
• Silent solid-state operation with no mechanical wear
• Screw terminals for easy and secure wiring
• Integrated protection: short-circuit, overload, overheat

Applications:

• Heavy-duty fan dimmer controller
• Smart home lighting control
• Industrial dimmable load automation
• Stage and event lighting systems
• AC motor speed control (resistive loads)
• Custom IoT and PLC-based projects

Technical Specifications:

• Load Capacity: 6A max @ 230V AC
• Dimming Type: Triac-based phase-cut
• Input Control: 3.3V / 5V logic compatible
• Output Type: AC load (resistive/inductive)
• Mounting: DIN rail or surface mount
• Cooling: Passive (heatsink recommended for full load)
